CVTK DF1 Vehicle-mounted Drone Detection System,24 hours Automatic Detection For DJI Mavic Phantom FPV,Xiaomi,Yuneec,Hubson

Number

Index

Parameter

Notes

1

Detection and

identification of

drone types

DJI series drones, FPVs, Xiaomi,

Yuneec, Hubsan, Hubson, Powervision, Tello drones etc.

2

Localizable drone models

DJI mavic ,air ,mini ,FPV ,avata. etc

3

Detection

frequency band

100MHz~6GHz

4

Detection and

positioning

distance

1~5km

Depending on

the

environment

5

Detection height

0m~1000m

6

Number of targets

that can be

detected

simultaneously

≥10 sorties

7

Capable of

simultaneously

tracking and

displaying drone

trajectories

≥5strip

8

Azimuth error

≤1°(RMS)

9

Positioning

accuracy

≤10m

10

Detection success rate

≥97%

11

Identify response time

≤3s

Number

Index

Parameter

Notes

1

Operation mode

Radio jamming suppression

2

Object of action

UAV image transmission, flight control link, navigation signal

3

Action

frequency

band

(820±10)MHz～(960±10)MHz;

(1545±10)MHz～(1650±10)MHz; (2390±10)MHz～(2520±10)MHz; (5690±10)MHz～(5880±10)MHz

4

Transmitting power

Output power of each port (average power): Channel 1:(41±2)dBm;

Channel 2:(40±2)dBm;

Channel 3:(41±2)dBm;

Channel 4:(37±2)dBm

5

Reverse

distance

1.5km-2km (there maybe some differences depending on the environment and model)

Depending on

the

environment

6

Counter

mode

Directional and omnidirectional
