1、It adopts ultra-high frequency broadband seamless interference technology。
2、 Single switch technology controls the power output。
3、The effective power (channel power) is high, and the interference distance is long。
4、 Effective segmentation, only interferes with the drone control and video transmission frequency, and does not interfere with other frequencies。
5、It adopts a built-in battery (push-pull design, the battery is removable), which lasts about 0.7 hour and charges for 4 hours。
6、Imported devices, slow start circuit design, can avoid the ignition phenomenon caused by mechanical switch, high integration, stable work。
Device operating frequency
|
Output |
Operating frequency |
Average output power |
Channel output power |
|
1.5G |
1550-1620MHz |
44dBm |
20dBm/30KHz(min) |
|
2.4G |
2400-2500MHz |
44dBm |
20dBm/30KHz(min) |
|
5.8G |
5720-5850MHz |
43dBm |
20dBm/30KHz(min) |
|
900M |
860-930MHz |
44dBm |
20dBm/30KHz(min) |
|
1.2G |
1180-1280MHz |
40dBm |
20dBm/30KHz(min) |
|
5.2G |
5150-5250MHZ |
42dBm |
20dBm/30KHz(min) |
|
433MHz |
433MHz |
40dBm |
20dBm/30KHz(min) |
|
1.4G |
1380-1450MHZ |
40dBm |
20dBm/30KHz(min) |
|
power supply:AC220V-DC5V Electrical energy consumption:About 280W |
|||
